Transform your living space with more natural light and large openings.  Our European lift-and-slide doors are engineered for extra-large openings to offer unobstructed views, abundant natural light, and seamless indoor-outdoor living – without compromising ease of operation, performance or security.



Lift-and-Slide Operation

A simple turn of the handle disengages the secure locking mechanism and effortlessly lifts the door upwards off the compression seals, allowing it to smoothly glide along a series of rollers in the track.  The door slides free of the air-tight seals, eliminating wear and making opening and closing effortless.

The door can also be lowered and locked in any partially-open position.

When in the closed position, our lift-and-slide doors deliver an air-tight seal around the entire frame thanks to multiple compression seals.  This coupled with our multi-point locking system, dramatically increases energy efficiency.

Our lift-and-slide doors feature a very low threshold that can easily be flush-mounted into your floor for a continuous surface from the inside to the outside.  The flush-mount threshold is an excellent choice for homes that need greater ease of accessibility for mobility devices, for high-traffic doors, or simply for homeowners who appreciate beautiful finishing details.

European Lift-and-Slide Doors v.s. Standard Sliding Doors

Standard sliding doors are more prone to air and water leakage due to an inherent design flaw and lack of compression seals.  In order for these panels to function and slide, they cannot have seals.  Instead they are equipped with loose-fitting bristle-brushes along the sliding edges and, in most cases, around the entire perimeter of the door.  Because these doors do not “lift and slide” away from their weather-stripping, the opening and closing motion is constantly causing friction and rubbing against the bristle-brushes, causing deformation, wear-and-tear and compromising their energy efficiency.

  • Sash depth: 75” (70 mm)
  • Frame depth:5” (167 mm)
  • Leaf dimensions: 9.8′ width x 8.2′ height (3 m x 2.5 m)
  • Rough opening: 21.3′ width x 9.2′ height (6.5 m x 2.8 m)
  • Glazing width: up to 1.6” (41 mm)
  • 2-Pane glazing package: 4/16Ar/4 [UgMetric=1.1 / Ug Imperial =0.1937 / R=5.2]
  • 3-Pane glazing package: 4/14Ar/4/14Ar/4 [Ug Metric=0.6 / Ug Imperial =0.1057 / R=9.5]
  • Ug Metric: metric 0.94; imperial 0.1656; R=6.0
  • Spacer: warm-edge spacer bar; optional Swisspacer bar
  • Rails: aluminum guiding rails
  • Seals: integrated multi-point compression seals
  • Reinforcements: rectangular steel reinforcements
  • Function: available in manual or HS-Master drive option, which automates the opening and closing of the door via the use of a wall switch, a remote control, or a push-and-go function activated by pushing the leaf or the handle.
  • Access control: physical key, digital keypad, fingerprint reader, Bluetooth module or a card reader for magnetic or proximity cards.
  • Security: safety glass, multiple anti-burglary bolts, and anti-burglary protection devices in the leaf corners.  Optional reed relays, magnetic sensors which could be connected to an alarm system.
  • Threshold: available in high and low-profile thresholds of 1.9” and 0.9” (47 mm and 22 mm)
  • Handles: option for a single handle on the inside, or double-sided handles with key lock
  • Colours: available in the full range of Aluplast colours

Aluplast Colour Options

Configurations

Loading...
  • Sash depth: 3” (85 mm)
  • Frame depth:75” (197 mm)
  • Leaf dimensions: 9.8′ width x 8.2′ height (3 m x 2.5 m)
  • Rough opening: 21.3′ width x 9.2′ height (6.5 m x 2.8 m)
  • Glazing width: up to 2” (51 mm)
  • 2-Pane glazing package: 4/16Ar/4 [UgMetric=1.0 / Ug Imperial =0.1761 / R=5.7]
  • 3-Pane glazing package: 4/14Ar/4/14Ar/4th [Ug Metric=0.5 / Ug Imperial =0.0880 / R=11.4]
  • Ug Metric: metric 0.77; imperial 0.1356; R=7.4
  • Spacer: warm-edge spacer bar; optional Swisspacer bar
  • Rails: aluminum guiding rails
  • Seals: integrated multi-point compression seals
  • Reinforcements: rectangular steel reinforcements
  • Function: available in manual or HS-Master drive option, which automates the opening and closing of the door via the use of a wall switch, a remote control, or a push-and-go function activated by pushing the leaf or the handle.
  • Access control: physical key, digital keypad, fingerprint reader, Bluetooth module or a card reader for magnetic or proximity cards.
  • Security: safety glass, multiple anti-burglary bolts, and anti-burglary protection devices in the leaf corners.  Optional reed relays, magnetic sensors which could be connected to an alarm system.
  • Filling: Premium Purenit insulating strips used in the frame and threshold
  • Threshold: available in high and low-profile thresholds of 1.8” and 0.9” (48 and 24 mm)
  • Handles: option for a single handle on the inside, or double-sided handles with key lock
  • Exterior finish: Possible to add aluminum skin to exterior of both frame and sash
  • Colours: available in the full range of Aluplast (for uPVC) and RAL (for Aluskin) colours

Aluplast Colour Options

RAL Colour Options Sample (Available in over 200 colours) (Aluminum Skin Only)

Configurations

  • Sash depth: 2” (82 mm)
  • Frame depth:6” (194 mm)
  • Leaf dimensions: 9.8′ width x 8.2′ height (3 m x 2.5 m)
  • Rough opening: 21.3′ width x 9.2′ height (6.5 m x 2.8 m)
  • Glazing width: up to 2” (52 mm)
  • 2-Pane glazing package: 4/16Ar/4 [UgMetric=1.0 / Ug Imperial =0.1761 / R=5.7]
  • 3-Pane glazing package: 4/14Ar/4/14Ar/4th [Ug Metric=0.5 / Ug Imperial =0.0880 / R=11.4]
  • Ug Metric: metric 0.78; imperial 0.1374; R=7.3
  • Spacer: warm-edge spacer bar; optional Swisspacer bar
  • Rails: aluminum guiding rails
  • Seals: integrated multi-point compression seals
  • Reinforcements: rectangular steel reinforcements
  • Function: available in manual or HS-Master drive option, which automates the opening and closing of the door via the use of a wall switch, a remote control, or a push-and-go function activated by pushing the leaf or the handle.
  • Access control: physical key, digital keypad, fingerprint reader, Bluetooth module or a card reader for magnetic or proximity cards.
  • Security: safety glass, multiple anti-burglary bolts, and anti-burglary protection devices in the leaf corners.  Optional reed relays, magnetic sensors which could be connected to an alarm system.
  • Threshold: available in high and low-profile thresholds of 2.7” and 0.9” (68 mm and 24 mm)
  • Handles: option for a single handle on the inside, or double-sided handles with key lock
  • Colours: available in the full range of Salamander colours

Salamander Colour Options

Configurations
